Engduino Extension with Arduino board manager

This is a trial version of Ardublock for Arduino. Unzip the zip file into Arduino software root directory, so that the Tools folder merge into the Tool folder of Arduino. Start Arduino software and configure the COM port and board option as usual. Make sure you start with a clean sketch. Go to Tools-Ardublock to launch.

Ardublock for Intel Edison Board #154 opened May 10, 2016 by sanyaade-teachings ArduBlock window will close without asking if you want to save your work. Install Arduino IDE. Download any version of Arduino IDE (here i'm using ver1.0.5) and install it on. For all the Ardublockly features to be enabled, the Ardublockly desktop application must be running locally on your computer. If you are using an online version you will not be able to configure the settings nor load the blocks code into an Arduino. Installation instruction can be found in the Ardublockly repository. Ardublock Introduction Youtube by mrromary2; Fixing the memory problem with Ardublock; Visual Programming Languages and Ardublock Beta 20140828 Keelen robots, DFRobot Bluno, more DuinoEDU blocks, String operations Scoop, other fun stuffs and bug fixes SCoop 20140704 Support for SCoop.

With this option, you would be able to use Engduino with any Arduino version from1.6.4+.

Windows Installer

The Windows installer is an all-in-one package that installs the drivers, Arduino files and Engduino libraries in a location of your choice.

Download the installer from the following location, double click and follow the instructions through to install Engduino software.

32/64 bit installer (Release V3.1.1)

Windows Installation Guide

Step-by-step installation guide. Help you to trouble shoot problems on the way

Download installation guide for Windows OS

MAC Installer

Ardublock Mac Os X

The MAC installer is an all-in-one disk image/package that contains all the essential drivers, Arduino files and Engduino libraries. .

Download the installer from the following location, open the disk image and follow the instructions through to install Engduino software.

Disk image (Release V3.1.0)

MAC Installation Guide

Step-by-step installation guide. Help you to trouble shoot problems on the way

Download installation guide for MAC OS

Engduino extension for Arduino/ Linux users

Visit our github repository to download Engduino Extension files with libraries and board definition

Zip extension for Engduino libraries and board definition only

Github location for Extension files

Extension installation guide

Step-by-step installation guide. Help you to trouble shoot problems on the way

Download installation guide for Engduino Extension

Ardublock trial version

This is a trial version of Ardublock for Arduino.

Ardublock

To use

  • Unzip the zip file into Arduino software root directory, so that the Tools folder merge into the Tool folder of Arduino.
  • Start Arduino software and configure the COM port and board option as usual.
  • Make sure you start with a clean sketch. Go to Tools->Ardublock to launch.

Quick troubleshooting

Ardublock for macbook air

Uploading doesn't work

Try these steps to reset/reconnect the Engduino to your computer:

  1. Turn the Engduino off and on
  2. Check the Tools->Serial Port menu and see that the COM port for the device is selected. Sometimes it disappears entirely.
  3. Check the Tools->Board menu and make sure Engduino V3 is selected.
  4. If it doesn't appear at all, then try shutting down and restarting the Arduino IDE
  5. If all else fails, then you can cause the Engduino to listen for an upload by double clicking the reset button. If you press the → upload symbol, then the code will compile and try to upload. The moment it starts trying to upload, double click the reset on the Engduino. You may need to experiment with timings a bit.

Other versions and tools

Visit our github repository to download other versions of Engduino source files and tools

Engduino Repositories

Ardublock For Macbook Pro

Hi, thanks for posting other ways to edit Ardublock.
I'm a teacher for kids age 10 - 12 and would love to simplify Ardublock for them: remove all blocks they'll never use. I only have some Seeed Grove Starter Kits. Is there a very simple way to remove the blocks? I edited the ardublock.xml-file, but I can't figure out how to compile that xml-file back in Ardublock. I miss the basic and most important stuff; how does it work? Do we need to edit some openblocks-scripts and put it in the master script or vice versa? Isn't there a really simple way? It would be so amazingly cool if this program would only contain the easy blocks.
